The RX DC combined with HyperSphere technology delivers high-definition images quickly and effortlessly. Designed for both comfort and precision, it is the ideal X-ray unit for any dental practice. With the RX DC HyperSphere, ergonomics, control, and image quality work in harmony to ensure consistently reliable diagnoses.

‍

• HyperSphere Technology – The ball-joint tube head moves easily in any direction, making it simple to position for comfort and accuracy.
• Clear Imaging – Produces sharp, detailed images for both digital sensors and film.
• Stable Power – High-frequency generator ensures consistent, reliable results while keeping patient exposure low.
• Ergonomic Design – Lightweight arms and easy-to-grip handles make positioning smooth and stable.
• Wireless Control – Remote operation gives the operator more freedom and improves safety.
• Automatic Settings – Adjusts exposure automatically based on patient size and anatomy.
• Low Radiation – Special design reduces scatter and exposure for safer imaging.
• Continuous Use – Can handle back-to-back imaging with built-in temperature monitoring.
• Flexible Installation – Various arm lengths (40, 60, 90 cm) fit any room setup.

• Tube Voltage: 60 / 65 / 70 kV (region-dependent)
• Tube Current: 4 / 8 mA
• Focal Spot: 0.4 mm (IEC 336)
• Exposure Time: 0.02 – 1.00 s (adjustable)
• Cone Length: 20 cm or 30 cm
• Collimation: Rectangular or round, 35×45 mm (typical)
• Arm Length Options: 40 cm / 60 cm / 90 cm
• Power Supply: 115–120 V or 230–240 V AC
• Rotation Range: Full 360° positioning via HyperSphere joint
• Duty Cycle: Continuous use with real-time temperature monitoring

‍
